| Tube O.D. (mm) | 8 | ||
| Tubing Material | PUER/PVC - UL94 | ||
| Color | RED | ||
| Vacuum Pressure Rating | 755 mm-Hg | ||
| Bend Radius | 20 mm | ||
| Application | Industrial Machinery, Compressed Air, Robotics, Mechanical Constraints, Cooling, Welding, Cabling | ||
| Specifications Met | UL94 V-0 (Fire resistance), DI: 2002/95/EC (RoHS), 2011/65/EC, RG: 1907/2006 (REACH) |
| Length (m) | 25 | ||
| Tube I.D. (mm) | 5, 5 | ||
| Maximum Operating Pressure | 14 barg | ||
| Weight | 1,620 kg/package | ||
| Number of Tubes | 1 | ||
| Media | Industrial fluids, compressed air, coolants |
