| Series | na | ||
| Shape | 2-way BSPP ball valve | ||
| Connection 1 Style | Female BSPP thread (ISO 1179-1) | ||
| Material | Steel, zinc plated, Cr(VI)-free | ||
| Connection Size | G 3/4 | ||
| Media | Hydraulic Fluids | ||
| Optional Accessories | na, Pre-assembled with nut and EO-PSR cutting ring, Pre-assembled with EO-2 functional nut, Pre-assembled with nut and EO-DPR cutting ring | ||
| Application | Agriculture Equipment, Automotive Process, Chemical Transfer, Construction Equipment, Fuel transfer, Hydraulic, Manufacturing Equipment, Marine, Material Handling, Mobile Equipment, Oilfield, Packaging, Transportation | ||
| Specifications Met | DIN ISO 8434 |
| Diameter Nominal (DN) | 20 | ||
| Connection 2 Tube O.D. (mm) | na | ||
| Pre-Installed Optional Accessories | na | ||
| Connection 1 Tube O.D. (mm) | na | ||
| Connection 2 Style | Female BSPP thread (ISO 1179-1) | ||
| Diameter | Nominal: 4.0 to 50 mm | ||
| Maximum Operating Pressure | 31.5-47.6 MPa, 315-500 bar, 4569-7252 psi | ||
| Connection Type | Bite Type, Soft Seal Bite Type |
