| material locking screw | stainless steel | ||
| Housing Material | polyamide fiber-glass reinforced | ||
| Vibration resistance | 10 - 55 hz, 1 mm | ||
| operational voltage ac, max. | 30 v ac | ||
| operating voltage dc, max. | 30 v dc | ||
| electrical connection 2, number of poles | 2-pin | ||
| Max. switching frequency | 400 hz | ||
| min. ambient temperature | -20 °c | ||
| certificates | atex, ce declaration of conformity, culus, rohs, ul (underwriters laboratories) | ||
| cable | with cable | ||
| indirect mounting for series | trb, its, ccl-is, mni, csl-rd, rpc, ics-d2, icm, khz, trr |
| Material cable sheath | polyurethane | ||
| cable length l | 5 m | ||
| Shock resistance | 30 g / 11 ms | ||
| operating voltage ac, min. | 5 v ac | ||
| operating voltage dc, min. | 5 v dc | ||
| electrical connection 2, type | open cable ends | ||
| max. ambient temperature | 60 °c | ||
| Protection class | ip67 | ||
| type of contact | reed | ||
| slot width | 6 mm t-slot | ||
| direct mounting for series | pra, pre, cci, kpz, ssi, gpc, cvi |
