| Bore diameter | d | 50 | mm |
| Width | B | 16 | mm |
| Basic static load rating, radial | C0r | 8,200 | |
| Limiting speed for grease lubrication | nG Grease | 24,000 |
| Outside diameter | D | 80 | mm |
| Basic dynamic load rating, radial | Cr | 12,800 | |
| Fatigue load limit, radial | Cur | 860 | N |
| Limiting speed for oil lubrication | nG Oil | 38,000 |
| Diameter shaft shoulder | da | 56 | mm |
| Shoulder diameter outer ring | Da | 74 | mm |
| Maximum recess radius | ra max | 0.30 | mm |
| Maximum diameter injection pitch | Etk max | 63 | mm |
| Diameter shaft shoulder clearance | da | h12 | |
| Shoulder diameter outer ring clearance | Da | H12 | |
| Minimum diameter injection pitch | Etk min | 59.60 | mm |
| Distance between the apexes of the pressure cones | a | 16.70 | mm |
| Minimum chamfer dimension | rmin | 1 | mm |
| Contact angle | α | 15 | ° |
| Manufacturer | Part Number |
|---|---|
| SKF | 7010CEGA/P4A |
| KOYO | ACH010CGLFTP4 |
| SNFA | VEX50-7CE1-UL |
| Fafnir | 2MMV9110HX-CRUL |
| IBC Waelzlager | 7010CCTPAPA7UL |
| SKF | 7010FBGA/P7 |
| RHP | T7010CTSULP2 |
| NTN | HSA010CGGNP4 |
| Fafnir | 2MMV99110WN-CRUL |
| IBC Waelzlager | H7010.C.TPA.P4A.UL |
| SNFA | HX50-7CE1-UL |
| GMN | SM6010CTAP4UL |
| RHP | T7010CTSULP3 |
