| Chamfer dimension outer ring | r1,2 | min.1 | |
| Diameter lubrication hole (outer ring) | M | 2.50 | mm |
| Width annular lubrication groove at outer ring | b | 3.80 | mm |
| Angle of tilt | α | 6 | ° |
| Width | B | 28 | mm |
| Bore diameter | d | 40 | mm |
| Chamfer dimension bore | r1 | min.0.6 | |
| Width annular lubrication groove at inner ring | b1 | 4 | mm |
| Raceway diameter inner ring | F | 53 | mm |
| Width Outer ring | C | 22 | mm |
| Outside diameter | d2 | 62 | mm |
