C55 SMC

SMC C55

187 Products

Discover all the available configurations for the SMC C55 product series C55 Compact Cylinder. Find the right product by filtering with Bore Size, Rod end thread and Weight.

C55 Type Codes

Series	Catalog Number Format	Description
C55	C55- - -[0-9]+	C55 Compact Cylinder

Typecode for Catalog Number C55, C55- - -[0-9]+

001	Series
C55	C55 Compact Cylinder
002	Mounting
B	Through-hole/Both ends tapped common (Standard)
L	Foot style
F	Rod side flange style
G	Head side flange style
C	Single clevis style
003	Bore Size
20	20 mm
25	25 mm
32	32 mm

004	Cylinder stroke (mm)
40	40 mm
50	50 mm
63	63 mm
80	80 mm
100	100 mm
[0-9]+	millimeter stroke
005	Rod end thread
M	Rod end male thread
	Rod end female thread

Products

Showing 1 product to 12 of a total of 187

Catalog Number	Part number	Weight
	C55B50-60	1Kg
	C55B100-50M
	C55B100-20M
	C55B100-40M
	C55B25-15M
	C55B100-100
	C55B20-20M
	C55B100-15
	C55B20-5
	C55B20-30M
	C55B25-25
	C55B25-10
