| adjusting knob | acetal resin | ||
| body | zinc alloy | ||
| bowl | aluminium | ||
| drain type | automatic drain | ||
| filter element | sintered plastic | ||
| gauge | no gauge | ||
| maximum inlet pressure imperial pressure psi | 246 psig | ||
| Medium | compressed air | ||
| operating temperature temperature celsius min to max range | -20 ... 80 °c | ||
| outlet pressure adjustment pressure bar min to max range | 0.3 ... 10 bar | ||
| product style | plug-in | ||
| relievingnonrelieving | relieving |
| Adjustment | knob | ||
| bonnet | aluminium | ||
| bowl type | metal with liquid level indicator | ||
| elastomers | polyurethane | ||
| filter element m particlesize micron | 40 μm | ||
| gauge port | 1/8" ptf | ||
| maximum inlet pressure pressure bar | 17 bar | ||
| operating temperature f temperature fahrenheit min to max range | -4 ... 176 °f | ||
| outlet pressure adjustment imperial pressure psig min to max range | 4 ... 145 psi | ||
| Port size | 1/4" ptf | ||
| range | b64g | ||
| Series | olympian plus |
