| fitting electronic interface | insertion 2 (inch) | ||
| product sub-group | fitting | ||
| diameter measuring tube (dn) | 110 mm | ||
| temperature medium max | 60 °c | ||
| nominal pressure (din en 1333) | pn 10 | ||
| armature material | pvc (polyvinyl chloride) | ||
| port connection material category | plastics | ||
| port connection 1 type | connection clamp | ||
| max measured value of volume flow rate | 5 | ||
| fluidic port connection number | 2 |
| installation length | 181 mm | ||
| Type | 1,501 | ||
| medium-contacting parts seal material | epdm (ethylene-propylene-diene rubber) | ||
| temperature medium min | 0 °c | ||
| measuring pipe material | pp (polypropylene without fibreglass) | ||
| port connection material | pp (polypropylene) | ||
| port connection 1 inner diameter (mm) | 125 mm | ||
| measured value unit | l/min | ||
| min measured value of volume flow rate | 167 | ||
| Customscode | 90269000 |
