| protection type ip (max. with suitable connector) | ip65 | ||
| electrical connection protective conductor | yes | ||
| electrical connection wire diameter min | 6 mm | ||
| electrical connection output direction | bottom | ||
| plug pattern | form a according to din en 175301-803 | ||
| product sub-group | cable plug | ||
| flat seal material | nbr (nitrile rubber) | ||
| temperature environment min | -10 °c | ||
| voltage max / rated voltage | 24 v | ||
| Customscode | 85369010 |
| plug mounting screw | iron steel fusion-bonded passivated | ||
| electrical connection wire diameter max | 7 mm | ||
| electrical connection outlet | angled (90°) | ||
| electrical connection number of contacts | 3 | ||
| connector with 3 to 2 conductor technology for pulse solenoids | yes | ||
| Type | 2,508 | ||
| temperature environment max | 55 °c | ||
| dc voltage | yes | ||
| voltage min / rated voltage | 6 v |
