| closing time (msec) (max) | 80 | ||
| opening time (msec) (max) | 60 | ||
| duty cycle (%) | 100 | ||
| ambient temperature (max) | 55 | ||
| medium temperature (degree c) (min) | -10 | ||
| pressure (bar) (min) | 0,3 | ||
| power consumption | 8 watt | ||
| voltage | 220-230 volts | ||
| Material | brass | ||
| orifice size | 12mm (7/16") | ||
| typ | 400 |
| closing time (msec) (min) | 60 | ||
| opening time (msec) (min) | 50 | ||
| qnn value (l/min) | 3,600 | ||
| medium temperature (degree c) (max) | 100 | ||
| pressure (bar) (max) | 14 | ||
| special feature | flange: thread m5 under electr. connection | ||
| frequency | 50-60 hz | ||
| port connection | g1/2 threaded port | ||
| seal material | fkm | ||
| circuit function | 2/2-ways; normally opened | ||
| Customscode | 84818079 |
