NORGREN 11-818-993 series precision pressure regulator

Name: 11-818-993 NORGREN
Brand: NORGREN
SKU: 778286-en-usd
Price: 350.94 USD
Availability: InStock

$350.94 ~~$701.88~~ -50%

2 pcs. with 3 to 4 week lead time shipping to United States

Specifications

max. pressure	4 bar

Width	54mm

adjusting knob		acetal resin
bonnet		zinc alloy
elastomers		synthetic rubber
gauge		no gauge
maximum inlet pressure imperial pressure psi		58 psig
Medium		compressed air
operating temperature f temperature fahrenheit min to max range		32 ... 158 °f
outlet pressure adjustment imperial pressure psig min to max range		1 ... 60 psi
height length millimetre		54 mm
width length millimetre		54 mm
Port size		g1/4
range		11-818

body		zinc alloy
data performance shelf life		3 years
eu country of origin		czechia
gauge port		r1/4
maximum inlet pressure pressure bar		4 bar
mil spec		unavailable
operating temperature temperature celsius min to max range		0 ... 70 °c
outlet pressure adjustment pressure bar min to max range		0.07 ... 4 bar
length length millimetre		127 mm
port connections		g1/4
product style		ported
relievingnonrelieving		relieving
