| Brand | snr | ||
| BRF - Rotational frequency – rolling element (60 rpm) | 2,876 Hz | ||
| BPFI - Over rolling frequency on inner (60 rpm) | 6,429 Hz | ||
| Adapter sleeve designation | H2317-48 | ||
| Operating temperature max. | 100 °C | ||
| C0 - Static load rating | 63,8 kN | ||
| f0 - Factor | 14,70 | ||
| d1 - Outer dia of eccent. Lock. collar / nut of adapter sleeve | 110 mm | ||
| C1 - Distance center of OR to center of lubrication zone | 11 mm | ||
| B2 - Width of eccentric locking collar/nut | 18 mm | ||
| B - Width of Inner Ring | 44 mm |
| FTF - Rotational frequency - cage (60 rpm) | 0,416 Hz | ||
| BSF - Over rolling frequency on rolling element (60 rpm) | 5,752 Hz | ||
| BPFO - Over rolling frequency on outer ring (60 rpm) | 4,571 Hz | ||
| mass | 3,72 kg | ||
| Operating temperature min. | -20 °C | ||
| C - Dynamic load rating | 83,2 kN | ||
| D - Outer diameter of OR | 150 mm | ||
| d - Shaft diameter | 76,2 mm | ||
| C - Width of Outer Ring | 35 mm | ||
| B1 - Overall width Inner Ring | 82 mm |
