| Brand | snr | ||
| mass | 0,67 kg | ||
| Operating temperature min. | -20 °C | ||
| C - Dynamic load rating | 12,8 kN | ||
| N1 - Mounting hole length | 19 mm | ||
| L1 - Housing foot length | 42 mm | ||
| J - Mounting holes distance | 95 mm | ||
| H1 - Housing foot height | 15 mm | ||
| G - Grease fitting | M6x1 | ||
| B - Width of Inner Ring | 31 mm | ||
| A - Housing width | 38 mm |
| Recommended tightening torque for set screw | 3,7 N-m | ||
| Operating temperature max. | 200 °C | ||
| C0 - Static load rating | 6,65 kN | ||
| S - Distance front side/bearing centre | 12,7 mm | ||
| N - Mounting hole dimension | 13 mm | ||
| L - Housing length | 127 mm | ||
| H2 - Housing height | 65 mm | ||
| H - Distance mounting base to centerline spheric. seating diam. | 33,3 mm | ||
| d - Shaft diameter | 19,05 mm | ||
| A1 - Housing top width | 22 mm |
