| Tipo | sa1-ma | ||
| Carrera | 50 mm | ||
| max. energy absorption/hour | 150000 nm | ||
| Medio | oil | ||
| max. ambient temperature | 80 °c | ||
| effective mass me max. | 4000 kg | ||
| return spring force max. | 50 n | ||
| impact speed max. | 6 m/s | ||
| Peso | 0.55 kg | ||
| Material del vástago | stainless steel | ||
| material lock nut | steel |
| Mounting thread | m33x1,5 | ||
| max. energy absorption/stroke | 500 nm | ||
| Amortiguación | adjustable | ||
| min. ambient temperature | -20 °c | ||
| effective mass me min. | 100 kg | ||
| return spring force min. | 23 n | ||
| impact speed min. | 0.02 m/s | ||
| mounting | lock nut | ||
| material cylinder tube | steel | ||
| material stop | steel | ||
| scraper material | polyurethane |
