| Outside Diameter D | 110 | mm | |
| Outside Ring Width C | 27 | mm | |
| Center of Bearing from End S | 31 | mm | |
| Number of Set Screws | 2 | ||
| Dimensión d1 | 84,10 | mm | |
| Dimensión B1 | 77,80 | mm |
| Inner Ring Width B | 61,91 | mm | |
| Radius r | 0,60 | mm | |
| Set Screw Size | M12x1.75 | ||
| Angle between Set Screws | 90 º | ||
| Dimensión M | 5,13 | mm | |
| Dimension B2 | 22,20 | mm |
| Manufacturing Part Number | GE60KRRB + COL | ||
| Bore Type | Cylindrical bore | ||
| Material | Bearing Steel | ||
| O.D. Type | Spherical OD | ||
| Sub Series | GE..KRRB | ||
| Peso | 0,20 | Kg |
| Shaft Size d | 60 | mm | |
| Bearing Type | Ball Bearing | ||
| Modelo de lubricación | Relubricatable | ||
| Serie | Industrial | ||
| Seal Type | Shroud Seal |
