| Connection 1 Tube O.D. (mm): | 8 | ||
| Fitting Material: | Steel, Chromium-6 Free | ||
| Series: | Heavy | ||
| Connection 1 Tube Outside Diameter: | 06 to 42 mm | ||
| Shape: | Female connector | ||
| Optional Accessories: | na, Pre-assembled with nut and EO-PSR cutting ring, Pre-assembled with EO-2 functional nut, Pre-assembled with nut and EO-DPR cutting ring | ||
| Maximum Operating Pressure: | 16-40 MPa, 160-400 bar, 2321-5802 psi | ||
| Connection Type: | Bite Type, Soft Seal Bite Type | ||
| Materials of Construction: | Steel zinc plated (CrVI-free), Stainless steel |
| Pre-Installed Optional Accessories: | Pre-assembled with EO-2 functional nut | ||
| Connection 2 Style: | Female BSPP thread (ISO 1179-1) | ||
| Connection Size: | G 1/8 to G 1 1/2; M 10x1.0 to M 48x2.0; 1/8-27 NPT to 1 1/2-11.5 NPT | ||
| Connection 2 Size: | Female metric thread (ISO 9974-1), Female BSPP thread (ISO 1179-1), Female NPT thread (SAE 476) | ||
| Product Series: | Light, Heavy | ||
| Tube Outside Diameter: | 6-42 mm | ||
| Application: | Agriculture Equipment, Automotive Process, Chemical Transfer, Construction Equipment, Fuel transfer, Hydraulic, Manufacturing Equipment, Marine, Material Handling, Mobile Equipment, Oilfield, Packaging, Transportation | ||
| Specifications Met: | DIN ISO 8434 |
