Descubre todas las configuraciones disponibles para la serie de produtos SMC CJ5 CJ5-S Stainless Steel Cylinder. Encuentra el producto correcto filtrando por Mounting, Bore Size, Material de Sellado y Peso.
Códigos del producto CJ5
| Serie | Formato de número de catálogo | Descripción |
|---|---|---|
| CJ5 | CJ5- - -S- -[0-9]+ | CJ5-S Stainless Steel Cylinder |
| 001 | Series |
|---|---|
| CJ5 | CJ5-S Stainless Steel Cylinder |
| 002 | Mounting |
| B | Through-hole/Both ends tapped common (Standard) |
| L | Foot style |
| F | Rod side flange style |
| D | Double clevis type |
| 003 | Bore Size |
| 10 | 10 mm |
| 16 | 16 mm |
| 004 | Stainless steel cylinder |
| S | S Stainless steel cylinder |
| 005 | Seal material |
|---|---|
| R | NBR |
| V | FKM |
| 006 | Cylinder stroke (mm) |
| [0-9]+ | millimeter stroke |
| 007 | Head cover port position |
| R | Axial direction |
| Perpendicular to axis |
| Referencia | Peso |
|---|---|
| CJ5B16SR-75 | |
| CJ5B16SV-15 | |
| CJ5B16SV-30 | |
| CJ5D16SR-75 | |
| CJ5D16SR-45 | |
| CJ5L16SR-60 | |
| CJ5D10SR-15 | |
| CJ5B16SR-30 | |
| CJ5B10SR-75 | |
| CJ5D10SV-75 | |
| CJ5B10SR-30 | 201g |
| CJ5D16SV-45 | 161g |
