| Material de la carcasa | aluminum | ||
| pressure for determining piston forces | 6,3 bar | ||
| Medio | compressed air | ||
| speed max. | 0.5 m/s | ||
| retracting piston force | 148 n | ||
| easy2combine | capable with connection kit | ||
| oil content of compressed air min. | 0 mg/m³ | ||
| min. ambient temperature | 0 °c | ||
| working pressure min. | 2 bar | ||
| magnetic piston | with magnetic piston | ||
| Principio de funcionamiento | double-acting | ||
| piston rod Ø | 10 mm |
| Peso | 1.31 kg | ||
| max. particle size | 50 µm | ||
| impact energy | 0.15 j | ||
| extracting piston force | 198 n | ||
| port | m5 | ||
| oil content of compressed air max. | 5 mg/m³ | ||
| max. ambient temperature | 65 °c | ||
| working pressure max | 10 bar | ||
| Amortiguación | non-adjustable | ||
| Bearing Type | ball bearing | ||
| Carrera | 100 mm | ||
| piston Ø | 20 mm |
