| product sub-group | on/off valves | ||
| ball bore | straight through bore | ||
| breakaway torque | 117 n m | ||
| interface actuator/fitting flange | f07 | ||
| medium-contacting parts seal material | ptfe (polytetrafluorethylene) | ||
| temperature medium min | -10 °c | ||
| ball material | stainless steel 1.4401 (a182 - 316) | ||
| port connection 1 dn | dn 80 | ||
| valve function number of switching positions | 2 | ||
| Customscode | 84818081 |
| Tipo | tku001 | ||
| running torque | 82 n m | ||
| interface actuator/fitting shaft | 17 mm | ||
| mounting flange according to iso 5211 | yes | ||
| temperature medium max | 200 °c | ||
| armature housing material | stainless steel 1.4408 (a351 - cf8m) | ||
| armature variant | compact flange | ||
| manual actuation type | rotary actuation | ||
| fluidic port connection number | 2 |
