| closing time (msec) (max) | 30 | ||
| opening time (msec) (max) | 20 | ||
| duty cycle (%) | 100 | ||
| kv value (m*3/h) | 0,120 | ||
| ambient temperature (min) | -10 | ||
| medium temperature (degree c) (min) | -10 | ||
| pressure (bar) (max) | 30 | ||
| frequency | 50-60 hz | ||
| Port connection | g1/4 threaded port | ||
| seal material | fkm | ||
| circuit function | 2/2-ways; normally closed | ||
| Customscode | 84818079 |
| closing time (msec) (min) | 20 | ||
| opening time (msec) (min) | 10 | ||
| qnn value (l/min) | 130 | ||
| ambient temperature (max) | 55 | ||
| medium temperature (degree c) (max) | 130 | ||
| pressure class (pn) | 100 | ||
| power consumption | 10 watt | ||
| voltage | 230 volts | ||
| Material | brass | ||
| orifice size | 2,0mm (5/64") | ||
| typ | 255 |
