| max. particle size | 50 µm | ||
| min. medium temperature | -20 °c | ||
| stroke max. | 2100 mm | ||
| weight 0 mm stroke | 1.35 kg | ||
| Conexiones | g 1/4 | ||
| working pressure min. | 2 bar | ||
| min. ambient temperature | -20 °c | ||
| retracting piston force | 1077 n | ||
| scraper | standard industrial scraper | ||
| environmental requirements | industry standard | ||
| Amortiguación | pneumatic adjustable cushioning | ||
| Carrera | 200 mm | ||
| Estándares | cnomo / nfe 49-001 |
| max. medium temperature | 80 °c | ||
| Medio | compressed air | ||
| weight +10 mm stroke | 0.068 kg | ||
| Rosca del vástago | m16x1,5 | ||
| working pressure max | 10 bar | ||
| max. ambient temperature | 80 °c | ||
| extracting piston force | 1077 n | ||
| pressure for determining piston forces | 6,3 bar | ||
| piston rod | through | ||
| magnetic piston | piston with magnet | ||
| Principio de funcionamiento | double-acting | ||
| piston Ø | 50 mm |
