| front foil material | polyester | ||
| protection class measurement device (ip) | ip65 | ||
| operating supply type | 2 conductor | ||
| electrical connection 1 material category | plastics | ||
| electrical connection 1 gender | terminal block | ||
| electrical connection 1 type | cable gland m20 | ||
| construction device | compact | ||
| Tipo | se35 | ||
| volumeter | yes | ||
| output 1 digital transistor connection pnp | yes | ||
| digital output 1 transistor contactless | 0,1 a | ||
| output 1 type analog current | 4-20 ma | ||
| protective cover seal material | silicone | ||
| temperature environment max | 60 °c | ||
| temperature medium max | 100 °c | ||
| electronics body material | pc (polycarbonate) | ||
| protective cover material | pc (polycarbonate) | ||
| screws material | stainless steel | ||
| dc voltage min | 12 v | ||
| flow rate (volume) | yes | ||
| paddle wheel measuring principle detection | hall | ||
| Customscode | 90261021 |
| front foil material category | plastics | ||
| Tipo de indicación | display | ||
| electrical connection 1 material | pa (polyamide) | ||
| electrical connection seal 1 material | neoprene | ||
| electrical connection 1 quantity | 2 pce | ||
| fitting electronic interface | inline | ||
| product sub-group | flow rate | ||
| parametrisation local | yes | ||
| continuous measurement | yes | ||
| output 1 digital transistor connection npn | yes | ||
| output 1 digital type | transistor | ||
| output type analog quantity | 1 | ||
| seal housing/cover material | nbr | ||
| temperature environment min | -10 °c | ||
| temperature medium min | -15 °c | ||
| electronics body material category | plastics | ||
| cover material | pc (polycarbonate) | ||
| dc voltage max | 36 v | ||
| precision of volume flow rate in relation to reading | 1 % | ||
| paddle wheel type | magnetic | ||
| Sensor type | paddle wheel / oval gear |
