| protection class measurement device (ip) | ip65 | ||
| electrical connection 1 material | pa (polyamide) | ||
| cable plug art. no. - type | 00572264 - 2518 | ||
| electrical connection 1 gender | terminal block | ||
| electrical connection 1 quantity | 1 pce | ||
| fitting connection thread | g | ||
| fitting electronic interface | insertion 2 (inch) | ||
| product sub-group | analysis | ||
| cell constant | k=0,01 1/cm | ||
| sensor/housing seal material | fkm (fluororubber) | ||
| temperature environment min | 0 °c | ||
| temperature medium min | 0 °c | ||
| electronics body encapsulated | resin | ||
| electronics body material category | plastics | ||
| measured value unit | µs/cm | ||
| measured value min | 0,05 | ||
| measuring accuracy 1 | 3 | ||
| conductivity conductive | yes | ||
| sensor holder material | pvdf (polyvinylidene fluoride) | ||
| electrode material | stainless steel | ||
| Customscode | 90278930 |
| Tipo de indicación | no display | ||
| electrical connection 1 material category | plastics | ||
| cable plug in delivery | enclosed | ||
| electrical connection 1 number of contacts | 4 pce | ||
| fitting connection thread marking | 2 | ||
| fitting connection type | outer thread | ||
| construction device | compact | ||
| Tipo | 8.220 | ||
| medium-contacting parts seal material | fkm (fluor rubber) | ||
| temperature environment max | 60 °c | ||
| temperature medium max | 100 °c | ||
| nominal pressure (din en 1333) | pn 10 | ||
| electronics body material | pehd | ||
| nut material | pc (polycarbonate) | ||
| measured value max | 20 | ||
| measuring accuracy temperature (°c) | 1 °c | ||
| temperature | yes | ||
| insertion sensor length | short | ||
| sensor holder material composition | plastics | ||
| number of electrodes | 2 pce |
