Bürkert

42005 Bürkert

42005-1
42005-2

BURKERT 42005

$804,31
disponible con envío de 3 a 7 días a Mexico

Especificaciones

Actuation Type key button
Tensión de alimentación 230 v
Junta fkm (fluor rubber)
Peso 1,04Kg
thermal insulation class of the actuator h
coil insulation material (encasement) epoxy
protection type ip (max. with suitable connector) ip65
electrical connection position top
electrical connection number of contacts 2 + grounding conductor
switch time close max. 4.000 ms
switch time open max. 800 ms
switch function on/off
main valve operating principle diaphragm valve
media separation yes
actuator type pivot
main valve orifice 1 (inch) 3/4 inch
pilot control orifice (mm) 2 mm
kv value (water) 6 m3/h
pilot control seal material fkm (fluor rubber)
seat seal material fkm (fluor rubber)
temperature environment max 40 °c
temperature medium max 50 °c
nominal pressure max (liquid) 6 bar
pilot control material medium-contacting pvdf (polyvinylidene fluoride)
ac voltage yes
voltage tolerance positive 10 %
voltage max / rated voltage 230 v
port connection 2 inner diameter (mm) 25 mm
port connection 2 type bonded sleeve
port connection 1 inner diameter (mm) 25 mm
manual actuation stop yes
manual actuation type key button
Función de la válvula a - normally closed - inlet port 1 (p/nc)
fluidic port connection number 2
coil wiring overvoltage protection without
coil type block bolted
cable plug art. no. - type 00314802 - 2518
cable plug in delivery enclosed
nominal operation/duty cycle 100 %
switch time close min 1.000 ms
switch time open min 100 ms
valve construction valve complete
flow above seat
operation servo-controlled
Tipo 142
main valve orifice 1 (p) (mm) 20 mm
qnn value (gas) 6.400 l/min
rated power consumption 5 w
sealing toward outside material fkm (fluor rubber)
seat seal material category elastomer
temperature environment min 0 °c
temperature medium min 0 °c
nominal pressure min 0,5 bar
main valve wetted material pvc (polyvinyl chloride)
voltage tolerance negative 10 %
voltage frequency 50/60 hz
voltage min / rated voltage 230 v
port connection 2 size dn dn 20
port connection 1 size dn dn 20
port connection 1 type bonded sleeve
manual actuation material pa (polyamide)
manual actuation yes
valve function number of switching positions 2
Customscode 84818079
