| reduced power dc | 8 w | ||
| thermal insulation class of the actuator | h | ||
| coil insulation material (encasement) | epoxy | ||
| protection type ip (max. with suitable connector) | ip65 | ||
| cable plug in delivery | not included | ||
| installation length | 65 mm | ||
| nominal operation/duty cycle | 100 % | ||
| switch time close min | 22 ms | ||
| switch time open min | 17 ms | ||
| valve construction | valve complete | ||
| flow | above seat | ||
| operation | servo-controlled | ||
| Tipo | 6.430 | ||
| main valve orifice 1 (p) (mm) | 8 mm | ||
| kv value (water) | 0,95 m3/h | ||
| sealing toward outside material | nbr (nitrile rubber) | ||
| seat seal material category | elastomer | ||
| temperature environment min | 0 °c | ||
| temperature medium min | 0 °c | ||
| nominal pressure min | -1 bar | ||
| main valve wetted material | brass | ||
| battery voltage | yes | ||
| voltage tolerance negative | 0 % | ||
| voltage frequency | 0 hz | ||
| voltage min / rated voltage | 24 v | ||
| port connection 3 thread type | g | ||
| port connection 2 thread marking | 1/4 | ||
| port connection 2 type | inner thread | ||
| port connection 1 thread marking | 1/4 | ||
| manual actuation position | above port 1 | ||
| manual actuation material | pa (polyamide) | ||
| manual actuation | yes | ||
| fluidic port connection number | 3 |
| rated power dc | 8 w | ||
| coil wiring overvoltage protection | without | ||
| coil type | block bolted | ||
| electrical connection position | top | ||
| electrical connection number of contacts | 2 + grounding conductor | ||
| vacuum version | yes | ||
| switch time close max. | 30 ms | ||
| switch time open max. | 25 ms | ||
| switch function | on/off | ||
| main valve operating principle | piston | ||
| media separation | yes | ||
| actuator type | pivot | ||
| main valve orifice 1 (inch) | 5/16 inch | ||
| qnn value (gas) | 1.022 l/min | ||
| rated power consumption | 8 w | ||
| seat seal material | nbr (nitrile rubber) | ||
| temperature environment max | 55 °c | ||
| temperature medium max | 80 °c | ||
| nominal pressure max (liquid) | 3 bar | ||
| pilot control material medium-contacting | brass | ||
| valve seat material | brass | ||
| dc voltage | yes | ||
| voltage tolerance positive | 0 % | ||
| voltage max / rated voltage | 24 v | ||
| port connection 3 thread marking | 3/8 | ||
| port connection 3 type | inner thread | ||
| port connection 2 thread type | g | ||
| port connection 1 thread type | g | ||
| port connection 1 type | inner thread | ||
| manual actuation stop | yes | ||
| manual actuation type | rotary level and key button combined | ||
| valve function number of switching positions | 2 | ||
| Customscode | 84818079 |
