| kv value (m*3/h) | 4,7 | ||
| ambient temperature (min) | -10 | ||
| medium temperature (degree c) (min) | -10 | ||
| pilot pressure (min.) | 4 | ||
| actuator size | dm 40mm | ||
| Material | gunmetal | ||
| orifice size | 15mm (9/16") | ||
| Función de control | closed by spring force | ||
| Customscode | 84818071 |
| ambient temperature (max) | 30 | ||
| medium temperature (degree c) (max) | 185 | ||
| pilot pressure (max.) | 10 | ||
| pressure (bar) (max) | 15 | ||
| Port connection | g 3/8 threaded port | ||
| seal material | ptfe | ||
| paths/positions | 2 ways / 2 position | ||
| typ | 2.000 |
