| protection type ip (max. with suitable connector) | ip65/67 | ||
| Mounting type | classic drive | ||
| Tipo | 8.697 | ||
| certification type | ul listed culus | ||
| temperature environment max | 60 °c | ||
| for actuator size 225mm | yes | ||
| for actuator size 125mm | yes | ||
| for actuator size 80mm | yes | ||
| for actuator size 50mm | yes | ||
| end position feedback bottom | green | ||
| end position feedback dc voltage | yes | ||
| end position feedback voltage min | 0 v | ||
| end position feedback internal | 2 pce | ||
| Customscode | 84819000 |
| electrical connection sort | screw terminal with cable feed-through | ||
| product sub-group | pneumatic control unit / position indicator | ||
| Función | position feedback sensor | ||
| approval type | ul | ||
| temperature environment min | -20 °c | ||
| for actuator size 175mm | yes | ||
| for actuator size 100mm | yes | ||
| for actuator size 63mm | yes | ||
| for actuator size 40 mm | yes | ||
| end position feedback top | yellow | ||
| end position feedback voltage max | 24 v | ||
| end position feedback external | 0 pce | ||
| end position feedback type | inductive proximity switch pnp |
