| valve raw body manufacture | cast | ||
| valve piloting type | pneumatic | ||
| flow | below seat | ||
| Tipo | 2.301 | ||
| body nominal size | 80 mm | ||
| kv value (water) | 73 m3/h | ||
| control air connection material | plastic | ||
| control air connection 2 pre-mounted | not equipped | ||
| control air connection diameter (mm) | 6 mm | ||
| control cone | yes | ||
| actuator material category | plastics | ||
| Position indicator | without | ||
| seal nipple body material | graphite | ||
| seat seal material category | metals | ||
| temperature environment min | -10 °c | ||
| temperature medium min | -10 °c | ||
| nominal pressure (din en 1333) | pn 25 | ||
| control pressure min | 5,6 bar | ||
| nominal pressure min | 0 bar | ||
| valve body surface treatment internal | unmachined | ||
| valve body material category | metals | ||
| port connection 1 flange | din en 1092-1 | ||
| port connection 1 type | flanged | ||
| cip capable | yes | ||
| fluidic port connection number | 2 |
| valve construction | valve complete | ||
| main valve operating principle | globe valve | ||
| product sub-group | process control valves | ||
| body nominal size (in) | 3 inch | ||
| orifice | 65 mm | ||
| actuator version | element | ||
| control air connection position | in line direction | ||
| control air connection 1 pre-mounted | not equipped | ||
| control air connection type | interface element | ||
| actuator material | pps (polyphenylene sulphide) | ||
| actuator size | 130 mm | ||
| approval type | material-approval-foods | ||
| seat seal material | stainless steel | ||
| temperature environment max | 100 °c | ||
| temperature medium max | 185 °c | ||
| nominal pressure (din en 1759) | class 150 | ||
| control pressure max | 7 bar | ||
| nominal pressure max | 16 bar | ||
| valve body surface treatment external | untreated | ||
| valve body material | stainless steel | ||
| port connection 1 flange pressure rating | pn 25 | ||
| port connection 1 size dn | dn 80 | ||
| sip capable | yes | ||
| Función de control | a - normally closed (nc) | ||
| Customscode | 84818073 |
