| protection type ip (max. with suitable connector) | ip66 | ||
| travel time (90°) | 7 s | ||
| Tipo | 3.003 | ||
| output 1 type analog current | without feedback | ||
| input 1 type analog voltage | without analog signal | ||
| angle of rotation | 90 deg | ||
| interface actuator/fitting flange | f05/f07 | ||
| actuator material | pa (polyamide) | ||
| Par de giro | 35 n m | ||
| temperature environment max | 55 °c | ||
| dc voltage | yes | ||
| voltage frequency | 50/60 hz | ||
| voltage min / rated voltage | 15 v | ||
| limit switch number | 2 pce |
| electrical connection 2 type | cable gland m20 | ||
| product sub-group | actuators | ||
| output 1 type analog voltage | without feedback | ||
| input 1 type analog current | ohne ansteuerung | ||
| heating resistors | yes | ||
| interface actuator/fitting shaft | 22 mm | ||
| mounting flange according to iso 5211 | yes | ||
| actuator material category | plastics | ||
| approval type | csa | ||
| temperature environment min | -10 °c | ||
| ac voltage | yes | ||
| voltage max / rated voltage | 30 v | ||
| valve function number of switching positions | 2 | ||
| Customscode | 85013100 |
