| Brand | snr | ||
| Da max - Max shoulder diameter OR | 91 mm | ||
| db - Min diameter for Sleeve | 50 mm | ||
| da max - Max shoulder diameter IR | 0 mm | ||
| BRF - Rotational frequency – rolling element (60 rpm) | 2,426 Hz | ||
| BPFI - Over rolling frequency on inner (60 rpm) | 8,351 Hz | ||
| Tmax - Max operating temperature | 200 °C | ||
| N lim - Mechanical Limit Speed | 6700 tr/min | ||
| Y2 - Upper axial load coefficient | 2,83 | ||
| Y0 - Static axial load coefficient | 1,86 | ||
| Cu - Fatigue limit load | 22,8 kN | ||
| C - Dynamic load | 206 kN | ||
| Radial clearance class | C4 | ||
| k - Hole diameter | 3 mm | ||
| Number of lubrication holes | 3 | ||
| D1 - Inner diameter outer ring | 85,8 mm | ||
| B - Bearing/Inner ring width | 36 mm | ||
| d - Internal diameter | 45 mm |
| ra max - Max shaft & housing fillet radius | 1,5 mm | ||
| Ce - Min length fro Sleeve | 5 mm | ||
| da min - Min shoulder diameter IR | 54 mm | ||
| FTF - Rotational frequency - cage (60 rpm) | 0,403 Hz | ||
| BSF - Over rolling frequency on rolling element (60 rpm) | 4,852 Hz | ||
| BPFO - Over rolling frequency on outer ring (60 rpm) | 5,649 Hz | ||
| Tmin - Min operating temperature | -40 °C | ||
| N ref - Reference thermal speed | 5300 tr/min | ||
| Y1 - Lower axial load coefficient | 1,90 | ||
| e - Coefficient | 0,36 | ||
| C0 - Static load | 187 kN | ||
| mass | 1,35 kg | ||
| Associated sleeve reference | H2309 | ||
| b - Groove width | 6,43 mm | ||
| rs - Min fillet radius | 1,5 mm | ||
| d2 - External diameter inner ring | 0 mm | ||
| D - External diameter | 100 mm |
