| closing time (msec) (max) | 12 | ||
| opening time (msec) (max) | 12 | ||
| duty cycle (%) | 100 | ||
| ambient temperature (max) | 55 | ||
| medium temperature (degree c) (max) | 100 | ||
| pressure (max) by gas | 6 | ||
| power consumption | 4 watt | ||
| voltage | 24 volts | ||
| Port connection | g1/8 threaded port | ||
| seal material | fkm | ||
| circuit function | 3/2-way; output a relieved in idle position | ||
| Customscode | 84818079 |
| closing time (msec) (min) | 7 | ||
| opening time (msec) (min) | 7 | ||
| kv value (m*3/h) | 0,060 | ||
| ambient temperature (min) | -10 | ||
| medium temperature (degree c) (min) | -10 | ||
| pressure (bar) (max) | 6 | ||
| frequency | dc | ||
| coil size | 20 mm | ||
| Material | brass | ||
| orifice size | 1,6mm | ||
| typ | 6.012 |
