| cylinder tube | steel, chrome-plated | ||
| seal material | acrylonitrile butadiene rubber | ||
| oil content of compressed air max. | 5 mg/m³ | ||
| max. particle size | 50 µm | ||
| min. medium temperature | -20 °c | ||
| Peso | 11.4 kg | ||
| working pressure max | 8 bar | ||
| max. ambient temperature | 70 °c | ||
| extracting piston force | 12000 n | ||
| pressure for determining piston forces | 8 bar | ||
| Conexiones | g 1/2 | ||
| piston ø | 160 mm |
| material, front cover | steel, chrome-plated | ||
| piston rod | steel, chrome-plated | ||
| oil content of compressed air min. | 0 mg/m³ | ||
| max. medium temperature | 70 °c | ||
| Medio | compressed air | ||
| Rosca del vástago | m20 | ||
| working pressure min. | 2 bar | ||
| min. ambient temperature | -20 °c | ||
| retracting piston force | 11600 n | ||
| Principio de funcionamiento | double-acting | ||
| Carrera | 50 mm |
